Infinity
Pin
Hardware Reference
7100-XXXX-62
7101-XXXX-63
Function
Hardware Specification Notes
C1-36 Analog_In_8 MAP Sensor 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the Setup Wizard Set Manif old
Pressure page f or setup and calibration.
Monitor the MAP [kPa] channel.
C1-37 Analog_In_9 Fuel Pressure 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the Setup Wizard Fuel Pressure
page f or setup and calibration. Monitor
the FuelPressure [psig] channel.
C1-38 Analog_In_10 Baro Sensor 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the Setup Wizard Barometric
Pressure page f or setup and calibration.
Monitor the BaroPress [kPa] channel.
C1-39 Analog_In_11 Shif t Switch Input 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the 1D lookup table 'Shif tSwitch' f or
setup. Also assignable to multiple
f unctions. See Setup Wizard f or details.
C1-40 Analog_In_12 Mode Switch 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the 1D lookup table 'ModeSwitch'
f or input state.
A multi-position rotary switch such as
AEM P/N 30-2056 is recommended.
Also assignable to multiple f unctions.
See Setup Wizard f or details.
C1-41 +5V_Out_1 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C1-42 +5V_Out_1 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C1-43 HighsideSwitch_1 HS1 (switched 12V)
0.7A max, High Side Solid State
Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options.
See 2D lookup table 'HS1_Table' f or
activ ation settings.
