AEM Infinity Supported Applications - Dodge HEMI Engine - Manual (Page 12)

12
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
7100-XXXX-62
7101-XXXX-63
Function
Hardware Specification Notes
C2-16 Analog_In_Temp_5 Airbox Temperature 12 bit A/D, 2.49K pullup to 5V
See AirboxTemp [C] table f or calibration
data and AirboxTemp [C] f or channel
data.
C2-17 Analog_In_Temp_6 Fuel Temperature 12 bit A/D, 2.49K pullup to 5V
See FuelTemp [C] table f or calibration
data and FuelTemp [C] f or channel data.
C2-18 Analog_In_13 Oil Pressure 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See Setup Wizard Oil Pressure page f or
setup options. See OilPressure [psig] f or
channel data.
C2-19 Analog_In_14
Traction Control Mode
/ Sensitiv ity
12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See the TC_SlipTrgtTrim [MPH] 1-axis
table. A multi-position rotary switch such
as AEM P/N 30-2056 is recommended.
C2-20 Analog_In_15
Exhaust Back
Pressure
12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
See Setup Wizard Exhaust Pressure
page f or setup options. See EBPress
[kPa] f or channel data.
C2-21 Analog_In_16 DBW1_TPSB [%] 12 bit A/D, 100K pullup to 5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the ECU.
C2-22 +5V_Out_2 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C2-23 +5V_Out_2 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C2-24 +5V_Out_2 +5V Out
Regulated, f used +5V supply f or
sensor power
Analog sensor power
C2-25 VR+_In_5
Driv en Right Wheel
Speed Sensor +
Dif f erential Variable Reluctance
Zero Cross Detection
See Driv en Wheel Speed Calibration in
the Setup Wizard Input Function
Assignment page.
C2-26 VR-_In_5
Driv en Right Wheel
Speed Sensor -
C2-27 VR-_In_4
Non Driv en Right
Wheel Speed Sensor
-
Dif f erential Variable Reluctance
Zero Cross Detection
See Non Driv en Wheel Speed
Calibration in the Setup Wizard Input
Function Assignment page.
