BMW 1995 E36 M3 Supported Application
6
© 2014 AEM Performance Electronics
LowSide Assignment – PWM Idle
In the Wizard LowSide Assignment tab confirm the following settings:
LS3 Setup:
Frequency
= 100 Hz
LS3_Duty X-Axis
= Engine Speed [RPM]
LS3_Duty Y-Axis
= Idle Position
LowSide Assignment – VANOS
In the Wizard LowSide Assigment tab confirm the following settings:
LS4 Setup:
Frequency
= 30 Hz
LS4_Duty X-Axis
= Engine Speed [RPM]
LS4_Duty Y-Axis
= VTEC_Active
In the Wizard Honda VTEC tab confirm the following settings:
VTEC Off Below RPM
= 2000
VTEC On Above RPM
= 2100
VTEC Off Below Throttle
= 35
VTEC On Above Throttle
= 40
Input Function Assignment
In the Input Function Assignment tab, choose Vehicle Speed Input and confirm the following setting:
Vehicle Speed Calibration = 0.50
