BMW 1995 E36 M3 Supported Application 10
© 2014 AEM Performance Electronics
C1-52 VR+_In_3
Driv en Lef t
Wheel Speed
Sensor +
C1-53 DBW1 Motor -
DBW Motor
Control Close
5.0A max Throttle Control Hbridge
Driv e
+12V to close
C1-54 DBW1 Motor +
DBW Motor
Control Open
5.0A max Throttle Control Hbridge
Driv e
+12V to open
C1-55 Power Ground Ground 28 Power Ground Connect directly to battery ground
C1-56 Injector 6 Injector 6 4
Saturated or peak and hold, 3A
max continuous
Injector 6
C1-57 Injector 5 Injector 5 3
Saturated or peak and hold, 3A
max continuous
Injector 5
C1-58 Injector 4 Injector 4 5
Saturated or peak and hold, 3A
max continuous
Injector 4
C1-59 Injector 3 Injector 3 31
Saturated or peak and hold, 3A
max continuous
Injector 3
C1-60 Power Ground Ground 34 Power Ground Connect directly to battery ground
C1-61 +12V +12V In 12 v olt power f rom relay
12 v olt power f rom relay . Relay must be controlled by
+12V Relay Control signal, pin C1-29 abov e.
C1-62 Injector 2 Injector 2 32
Saturated or peak and hold, 3A
max continuous
Injector 2
C1-63 Injector 1 Injector 1 33
Saturated or peak and hold, 3A
max continuous
Injector 1
C1-64 +12V +12V In 54 12 v olt power f rom relay
12 v olt power f rom relay . Relay must be controlled by
+12V Relay Control signal pin C1-29 abov e.
C1-65 +12V_SW Ignition Switch 56 10K pulldown
Full time battery power must be av ailable at C1-10
bef ore this input is triggered.
C1-66
Analog_In_Temp_
1 Coolant Temp
Sensor
78 12 bit A/D, 2.49K pullup to 5V See "Coolant Temperature" Setup Wizard f or selection.
C1-67
Analog_In_Temp_
2 Intake Air
Temperature
77 12 bit A/D, 2.49K pullup to 5V See "Air Temperature" Setup Wizard f or selection.
C1-68
Harness_Analog_I
n_Temp_3
Oil
Temperature
Sensor
12 bit A/D, 2.49K pullup to 5V
See 1D table OilTempCal table f or calibration data and
OilTemp [C] f or channel data.
C1-69 Stepper_2A Stepper 2A
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A Be sure that each internal coil of the stepper motor are
properly paired with the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-70 Stepper_1A Stepper 1A
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A Be sure that each internal coil of the stepper motor are
properly paired with the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-71 Stepper_2B Stepper 2B
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A Be sure that each internal coil of the stepper motor are
properly paired with the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-72 Stepper_1B Stepper 1B
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A Be sure that each internal coil of the stepper motor are
properly paired with the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-73 Power Ground Ground 55 Power Ground Connect directly to battery ground
C2-1 DBW2 Motor +
DBW Motor
Control Open
5.0A max Throttle Control Hbridge
Driv e
+12V to open
C2-2 DBW2 Motor -
DBW Motor
Control Close
5.0A max Throttle Control Hbridge
Driv e
+12V to close
C2-3 Power Ground Ground Power Ground Connect directly to battery ground
C2-4 Injector 7 Injector 7
Saturated or peak and hold, 3A
max continuous
Injector 7
