Page 18
18
© 2014 AEM Performance Electronics
P/N 30-3520
Step 13
Connect the adapter harness and USB
cables (not shown) to the AEM Infinity.
Step 14
Loosely install the ECU bracket with the
AEM Infinity back into the vehicle. It may be
necessary to push factory wire looms or
other components out of the way to make
room for the AEM Infinity.
