Operation
85 Model 10042 Rev. 11/03
3 Foot Truss Boom w/Winch - Outriggers Up
10042
4110377
28 4 8 12 16 20 24 0 ft
28
0 ft
4
8
12
16
20
24
32
36
40
44
-4
17
B
C
D
E
40°
0°
10°
20°
30°
50°
60°
27
A
WITH SKY TRAK APPROVED
TRUSS BOOM WINCH ONLY
ALWAYS
• travel slowly
• rig properly
• use two tethers
SWINGING LOADS can
cause MACHINE TIPOVER
which can result in death
or serious injury.
68°
SAFETY INSTRUCTIONS
Use only with vehicles
equipped with auxiliary
hydraulics.
Always connect couplers.
ASME B56.6 - 2002 PART lll
OH3590
