Operation
27
Model 10042
Rev. 11/03
Park Brake Switch
The Parking Brake Switch (3) has two positions:
ENGAGED ............toggle switch downward
DISENGAGED............toggle switch upward
The Parking Brake Switch (3) must be ENGAGED to permit engine starting.
A red LED, on the parking brake switch, and a light in the instrument cluster
will indicate the brake is ENGAGED.
The parking brake may be used to stop in an EMERGENCY situation.
However, use caution because the stop will be abrupt and the operator and
the load may be jolted forward unexpectedly.
With boom angles greater than 40°, this switch activates the locked mode of
the Stabil-TRAK system.
P
P
OS0121
OS1323
OH3240
3
