Operation
55 Model 10042 Rev. 11/03
Cab Heater & Fan Control
The cab heater controls (3) are located directly below the switch banks on
the right side dash panel. The control panel consists of: a variable speed
fan control knob (4) and a temperature control knob (5).
Control of air flow to the windshield is made by opening, closing or
redirecting the air vent louver on the front dash. The cab is heated by the
heater unit positioned under the operators seat.
To heat the cab:
• Turn temperature control knob (5) to far right position
(RED = HOT),
• Direct desired air flow by adjusting vent louvers,
• Turn fan control (4) to “3” (6) to assure rapid warm-up.
To defrost the cab:
• Turn temperature control knob (5) to the far right position
(RED = HOT),
• Direct desired air flow by adjusting vent louver,
• Turn fan control (4) to “3” (6) to assure rapid defrost.
OS1950
OS1950
OA1390
OH3340
3
4
5 6
