Model 577 Operating Manual 7
4.1.2 Keypad (Pushbuttons)
Three keypad areas provide fast access to various menus and easy editing of system parameters.
Blue Soft Keys Provide one touch access to the menus for setting up the System and channel
parameters. Pressing the appropriate Blue Soft Key will display the sub-menu
containing the corresponding parameters.
Arrow Keypad The left ( ◄) and right (►) arrow keys move the cursor to different positions
within the currently selected parameter. The Next key selects the next
parameter in the currently displayed menu
Numeric Keypad The number keypad allows parameters to be entered in a numeric format.
Standby/Power ( ) Pressing the Standby/Power button will turn on/off the device and will save the
current parameters before shutting down.
Run/Stop Pressing the Run/Stop will arm/disarm the system and begin generating
pulses if in the correct mode. If in triggered mode the system will be armed but
will not output pulses until a valid trigger.
4.1.3 Rotary Adjustment Knob
The Rotary Adjustment Knob may be used to adjust the currently selected parameter. The step size is controlled
by the position of the cursor; however, turning the knob faster will increase the step size. Pushing the knob will
perform functions similar to the Next key and select the next parameter in the currently displayed menu.
4.1.4 BNC Connectors
One Gate Input (GATE), one Trigger Input (TRIG), and up to 8 Channel Outputs are available on the front of the
unit.
