REMOVAL OF BUMPER
5.
When removing lower trim panels, a
plastic nut located on each side will need
to be prized open with a small flat blade
screwdriver to assist removal.
6.
Remove lower bumper retaining screws.
7.
Remove plastic engine bay cover above
grille area and set aside. Prise open
plastic plugs with small flat blade
screwdriver or similar as shown.
8.
Remove 3 x retaining screws from top of
grille
