PREPARATION TO VEHICLE
15. Remove tow hook and set aside
16. Remove the bracket holding the power
steering pipe
17. Mark out a hole 20mm (3/4”) up from the
original upper hole
18. Drill out to same diameter as upper hole as
shown
19. Then flatten tab.
20. Touch up bare surfaces with rust preventing
paint.
21. Pull up pipe and refit bracket as shown
