Last Rev Date: 26/6/2009
Page 2 of 18
Fitting instructions# 3787027
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
GENERAL CARE AND MAINTENANCE
By
choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products
in the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent
value. To keep your bar in original condition it is important to care and maintain it following these
recommendations:
Prior to exposure to the weather your bar should be treated to a Canuba based polish on all exposed
surfaces. It is recommended that this is performed on a six monthly basis or following exposure to
salt, mud, sand or other contaminants.
As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual
inspection of the bar is carried out, making sure that all bolts and other components are torqued to
the correct specification. Also check that all wiring sheaths, connectors, and fittings are free of
damage. Replace any components as necessary. This service can be performed by your local
authorized ARB Stockist.
FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
METRIC SOCKET SET
METRIC RING AND OPEN ENDED SPANNER SET
ELECTRIC DRILL
3 & 10mm DRILL BITS
SHARP KNIFE
PHILLIPS AND FLAT SCREW DRIVER SET
FELT TIP PEN
HACKSAW BLADE OR SMALL HAND SAW
FINE FILE OR SAND PAPER
ELECTRIC JIG SAW
METRIC TAPE MEASURE
ROLLS OF 12 mm & 50 mm WIDE MASKING TAPE
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT
:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE
Torque Nm
Torque lbft
M6 9Nm
7lbft
M8 22Nm
16lbft
M10 44Nm
32lbft
M12 77Nm
57lbft
NOTE:
♦ OPTIONAL FOG LAMPS TO SUIT THIS PRODUCT ARE P#6821201.
IF LOOM AND SWITCH
REQUIRED USE P#MD02 LOOM KIT, P#180209 SWITCH AND P#180215 SWITCH CAP FOR FOGS
♦ UP TO 900 SERIES ROUND OR 800 RECTANGULAR DRIVING OR FOG LAMPS SUIT THIS PRODUCT
