ARB 3450110 User Manual
Page 5
31 10 02
Page 5 of 16
3783013
10. Photo shows a finished cut flare.
11. The vehicle is now ready to fit mounting
system and bar.
(Grille and bumper removed, flares cut and
grille lug cut.)
12. To fit mounting system to vehicle, fit
captive nut channel in through front
apertures in vehicle crossmember on both
sides.
(Notch in channel must face front of vehicle)
