ARB 3450110 User Manual
Page 2
31 10 02
Page 2 of 16
3783013
USE
PART No
QTY
DESCRIPTION
6151232
10
BOLT M10 x 30mm
IMPACT ABSORBER
4581040
10
WASHER FLAT M10
MOUNTING SYSTEM
4581048
10
WASHER SPRING M10
4601044
2
CHANNEL CAPTIVE NUT (INSIDE CHASSIS RAILS)
4601045
2
CHANNEL CAPTIVE NUT (INSIDE CROSSMEMBER)
3756449
1
MOUNTING SYSTEM
BULL BAR TO
6151232
6
BOLT M10 x 30mm
IMPACT ABSORBERS
4581048
6
WASHER SPRING M10
4581040
8
WASHER FLAT M10
6151026
2
NUT M10
6151021
2
BOLT M8 x 20mm
CONTROL BOX BRACKET
4581044
2
WASHER FLAT M8
3751564
1
CONTROL BOX BRACKET
6151132
2
NUT FLANGE M8
NUMBER PLATE BRACKET 6151080
2
BOLT M6 x 20mm (BRACKET TO BAR)
6151046
4
WASHER FLAT M6 x 13mm
6151128
4
NUT FLANGE M6
6151017
2
BOLT M6 x 16mm (NUMBER PLATE TO BRACKET)
3751370
1
NUMBER PLATE BRACKET
TO BOLT INDICATORS TO BAR 6151126
2
BOLT M4 x 30mm
4581037
2
WASHER FLAT M4
5848283
2
WASHER PACKER NYLON
6151127
2
NUT NYLOC M4
8-9000lb WINCH
4581040
4
WASHER FLAT 3/8” x 1"
6151074
2
BOLT 1 ¾” x 3/8” UNC
180302
10
CABLE TIES
6191007
1
EXTRUSION RUBBER
WINCH PAN COVER
6521031
1
PANEL WINCH COVER
6151256
2
SCREW BUTTON HEAD M6 x 16mm
6151128
2
NUT FLANGE M6
AIR DEFLECTOR
3314463
1
AIR DEFLECTOR
6151017
4
BOLT M6 X 16mm
6151128
4
NUT M6 - FLANGE
4581072
4
WASHER FLAT M6 x 20mm
WASHER BOTTLE COVER
3314462
1
WASHER BOTTLE COVER
3756446
1
BRACKET COVER
6151022
2
BOLT M8 x 25mm
4581044
2
WASHER FLAT M8
6151132
2
NUT FLANGE M8
6151017
5
BOLT M6 x 16mm
4581072
3
WASHER FLAT M6 x 20mm
6151046
2
WASHER FLAT M6 x 13mm
6151128
5
NUT FLANGE M6
FLARE MOULDING
6191009
1
FLARE MOULDING
FOG LIGHT HOUSING
3162457
1
PLASTIC HOUSING RHS
AND FITMENT
3162456
1
PLASTIC HOUSING LHS
4581040
4
WASHER
INNER GUARD TO BAR
6151017
2
BOLT M6 x 16mm
4581072
2
WASHER FLAT M6 x 20mm
6151128
2
NUT FLANGE M6
TOOLS REQUIRED.
BASIC TOOL KIT, KEY HOLE SAW, TORX KEY T-15
