Last Rev Date: 14/10/2010

Page 2 of 22

Fitting instructions# 3787836

GENERAL CARE AND MAINTENANCE

choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products

in the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent
value. To keep your bar in original condition it is important to care and maintain it following these
recommendations:

Prior to exposure to the weather your bar should be treated to a Canuba based polish on all exposed

surfaces. It is recommended that this is performed on a six monthly basis or following exposure to
salt, mud, sand or other contaminants.

As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual

inspection of the bar is carried out, making sure that all bolts and other components are torqued to
the correct specification. Also check that all wiring sheaths, connectors, and fittings are free of
damage. Replace any components as necessary. This service can be performed by your local
authorized ARB Stockist.

FITTING REQUIREMENTS

REQUIRED TOOLS FOR FITMENT OF PRODUCT:

METRIC SOCKET SET

METRIC RING AND OPEN ENDED SPANNER SET

ELECTRIC DRILL 13MM CAPACITY

3, 7, 8.5, 10, 13 &19mm DRILL BITS (19mm holesaw)

SHARP KNIFE

PHILLIPS AND FLAT BLAD SCREW DRIVER SETS

FELT TIP NON PERMANENT MARKER PEN

HACKSAW BLADE

FINE FILE OR SAND PAPER

ELECTRIC JIG SAW

METRIC TAPE MEASURE

ROLLS OF 25 mm & 50 mm WIDE MASKING TAPE

TOUCH UP PAINT ± BLACK FAST DRYING ENAMEL

SCISSORS

COLD CHIZEL

HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT

Protective eyewear

Hearing protection

127(µ:$51,1*¶QRWHVLQWKHILWWLQJSURFHGXUHUHODWHWR2+6VLWXDWLRQVZKHUHWRDYRLGD
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.

FASTENER TORQUE SETTINGS:

SIZE

Torque Nm

Torque lbft

9Nm

7lbft

22Nm

16lbft

M10

44Nm

32lbft

M12

77Nm

57lbft

NOTE:

i OPTIONAL FOG LAMPS TO SUIT THIS PRODUCT ARE P#6821201.

IF LOOM AND SWITCH REQUIRED

USE P#MD02 LOOM KIT, P#180209 SWITCH AND P#180215 SWITCH CAP FOR FOGS

i UP TO 900 SERIES ROUND OR 800 RECTANGULAR DRIVING OR FOG LAMPS SUIT THIS PRODUCT
