ARB 3423030 User Manual
Page 2
01-09-06
Page 2 of 15
3783174
USE.
PART NO.
QTY
DESCRIPTION
Chassis Mount Assembly
3756781
3756794L
3756794R
6151095
6151135
4516049
4581050
4581007
6151104
6151139
6151133
4581040
4581048
6151232
6151026
1
1
1
4
4
6
6
6
2
2
2
10
6
4
4
Bracket Mount Assembly
Bracket Tension LHS
Bracket Tension RHS
Bolt M12 x 1.25 x 35mm
Nut M12 x 1.25
Washer Flat ½”
Washer Spring ½”
Washer Flat M12 x 4mm HD (Large )
Bolt ½”x 4”UNC
Nut ½’UNCNut M10 x 1.25
Nut M10 x 1.25
Washer Flat M10
Washer Spring M10
Bolt M10 x 1.5 x 30mm
Nut M10 x 1.5
Bull Bar To Chassis Mount
Assembly
6151304
6151232
4581040
4581048
6151026
6
10
14
10
4
Nut Cage M10 x 1.5
Bolt M10 x 1.5 x 30mm
Washer Flat M10 x 2mm
Washer Spring M10
Nut M10 x 1.5
Stone Tray to Bull Bar
6542063
6151300
6151180
4581072
4581036
1
8
8
8
8
Stone Tray
Nut Cage 6mm
Bolt M6 x 20mm
Washer Flat M6
Washer Spring M6
Buffers To Bull Bar
3162470R
3162470L
6151128
1
1
12
Buffer Standard RHS
Buffer Standard LHS
Nut Flange M6
Indicators To Bull Bar
6821151R
6821151L
6821116
6151308
6821152
180701
1
1
4
4
2
6
Indicator Kit, RHS
Indicator Kit, LHS
Nylon Plug
Screw, Self Drilling
Wiring Loom
Scotch Lock
Licence Plate To Bull Bar
6151128
6151046
6151180
3751313
4
4
4
1
Nut Flange M6
Washer Flat M6
Bolt M6 x 20mm
Bracket Number Plate
Miscellaneous
EG50
180302
BLB850
6151074
2
10
3
4
Rubber Grommet 3/8” ID
Cable Ties
Cable Black 850mm
3/8” x 13/4” UNC Bolts
