1 Introduction
5
1.3 Assembly Type Identification
IMPORTANT:
Sections 2 and 3 of this installation guide have been written to
accommodate two different application installations:
A the Independent Front Suspension (IFS) type with an
aluminum clamshell housing (Refer to Fig.1.)
B the live axle Salisbury type with a cast iron housing.
(Refer to Fig.2.)
To eliminate confusion, you should identify which figure your vehicle
matches with. The section numbers within the guide that refer ONLY
to the IFS type have been suffixed with an ‘
A ’, and those that refer
ONLY to the live axle type have been suffixed with a ‘ B ’.
PLEASE IGNORE ALL SECTIONS WHICH
DO NOT APPLY TO YOUR APPLICATION
Figure 1.
Figure 2.
A
B
