3 Installing the Air Locker

16


Figure 11.












Trial fit the seal housing to the clamshell as shown in Figure 9.
Mark the tube approximately 8-10mm out from the edge of the

housing (Figure 11.).

Remove the seal housing from the differential housing and trim the

tube to length.

NOTE :

Figure 10. shows a housing that has been saw-cut in
half. This has been done for illustration purposes so
that the seal housing tube profile and seal housing
bracket can be seen in position.
