3 Installing the Air Locker

22

3.7

B

Profiling the Seal Housing Tube

Without using sharp jagged tools such as pliers (your hands are the

best tool for this job) gently bend the seal housing tube in a shape
that will clear the differential and housing, and exit through the
bulkhead port as shown in Figure 17.

Trim the tube to length using an automotive brake line tube cutter.


NOTE :

Never use a hacksaw to cut the seal housing tube as
this will leave metal filings in the air system.

Figure 17.













Figure 18.
