7 Parts List
40
7.2
Itemized Parts List
(See exploded diagram figure 27.)
AIR LOCKER MODEL No. :
RD197
ITEM # QTY
DESCRIPTION
PART #
01
1
FLANGE CAP ASSEMBLY
028612
02
1
BONDED SEAL
160703
03
1
CLUTCH GEAR
050807
04
1
LONG CROSS SHAFT
061501
05
1
SHORT CROSS SHAFT
061601
06
2
SIDE GEAR THRUST WASHER
151007
07
1
DIFFERENTIAL CASE
013212
08
2
RETAINING PIN
120601
09
2
COUNTERSUNK SCREW
200214
10
2
TAPERED ROLLER BEARING
NOT SUPPLIED
11
1
SEAL HOUSING ASSEMBLY
080903
12
2
SEAL HOUSING O-RING
160239
13
12
RETURN SPRING
150107
14
1
SPLINED SIDE GEAR
728K131**
15
1
SPIDER BLOCK
070404
16
4
PINION GEAR
728K131**
17
4
PINION THRUST WASHER
151113
18
1
SIDE GEAR
728K131**
*
1
SEAL HOUSING BRACKET (LIVE AXLE)
220203
*
1
SEAL HOUSING BRACKET (IFS)
220211
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170111
*
1
PUSH-IN FITTING (5mm to 1/8”BSPP)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE (1/8” to 1/8” BSPT)
170501
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH
180209
*
1
SWITCH COVER (FRONT)
180210
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102197
* Not illustrated in exploded view.
** Available only as complete 6 gear set
