5 Mounting & Connecting the Electrical System
32
Figure 22.
5.2
Wiring the Actuator System
5.2.1
Connection to an ARB Air Compressor
When wiring the Air Locker actuator switch(es) and solenoid(s) to an
ARB Air Compressor, all connections can easily be set up directly from
the supplied wiring loom. (Fig.23.)
NOTE :
180409 model loom shown for reference only. Refer to
your ARB Air Compressor Installation Guide for
details on configuring your installation.
