3 a profiling the seal housing tube, 3 installing the air locker, Profiling the seal housing tube – ARB RD197 User Manual
Page 17
3 Installing the Air Locker
15
3.3
A
Profiling the Seal Housing Tube
The seal housing tube needs to be bent into a profile that will allow it
to clear the Air Locker and the differential housing, and exit through
the bulkhead port.
Bend the tube to the profile shown in Figures 9. & 10.
Figure 9.
Figure 10.
