Hale Master Intake Valve - Manual (Page 38)

36
M
ASTER
I
NTAKE
V
ALVE
VALVE DISC REPLACEMENT KIT
546-1620-00-0 1 VALVE DISC REPLACEMENT KIT
Consists of the following items:
505-0230-00-0 1 DISC
040-1159-00-0 1 QUAD-RING
040-9160-00-0 2 TRUNNION SEAL
046-6650-00-0 1 GEARBOX ADAPTER GASKET
142-0110-00-0 2 SQUARE SEAL RING
GEARMOTOR/GEARBOX REPLACEMENT ASSEMBLY
531-0150-50-0 1 GEARMOTOR/GEARBOX REPLACEMENT ASSEMBLY
Consists of the following items:
531-0150-00-0 1 GEARBOX
007-3330-00-0 1 GEARMOTOR ADAPTER
218-0608-08-0 4 SCREW, M6 x 16mm LG. SOC. HD.
064-6350-00-0 1 DRIVE PIN (1/8 DIA. x 7/8 LG.)
200-1250-50-0 1 GEARMOTOR ASSEMBLY
018-0604-08-0 4 SCREW, #6-32 x ½ LG. SOC. HD.
013-1360-00-0 1 GEARMOTOR WHITE WIRE
513-0270-05-0 1 GEARMOTOR WIRE HARNESS
044-1480-00-0 1 GEARMOTOR COVER
018-0604-45-0 4 SCREW, #6-32 x ½ LG. RD. HD.
101-0850-44-0 1 INSTRUCTION SHEET
MICRO SWITCH REPLACEMENT KITS
200-1210-50-0 1 MICRO SWITCH REPLACEMENT KIT, MANUALLY OPERATED VALVE
Consists of the following items:
200-1210-00-0 2 POSITION MICRO SWITCH
018-0404-45-0 4 SCREW, #4-40 x ½ LG. RD. HD.
046-6650-00-0 1 GEARBOX ADAPTER GASKET
101-0850-49-0 1 INSTRUCTION SHEET
200-1210-52-0 1 MICRO SWITCH REPLACEMENT KIT, ELECTRIC MOTOR OPERATED VALVE
Consists of the following items:
200-1210-00-0 4 POSITION MICRO SWITCH
159-1520-00-0 2 SWITCH SPACER
018-0410-45-0 4 SCREW, #4-40 x 1” LG. RD. HD.
046-6650-00-0 1 GEARBOX ADAPTER GASKET
101-0850-49-0 1 INSTRUCTION SHEET
