Connecting the receiver unit to the TV
1 Position the receiver unit close to the TV.
2 Connect the RCA to SCART adapter (20) supplied to the
SCART connector of the TV.
3 Connect the video cable (19) and audio cable (18) supplied to both the
adapter and the TV OUTPUT connectors (15) of the receiver.
Make sure to insert the yellow plugs into the yellow video in- and outputs
and the red and white plugs into the red and white audio in- and outputs.
4 Connect the AC power adapter (17) to a mains socket and to the
DC 9V —<± supply socket (14) of the receiver unit.
Note: In case your TV is equipped with RCA connectors you can directly connect
the TV OUTPUT connectors (13) of the receiver to the corresponding RCA
connectors of the TV. Make sure to insert the yellow, white and red plugs
into the yellow, white and red inputs on both receiver and TV.
Channel selection
• Set the CHANNEL switches (6 and 16) on both units to channel 1.
• If interference occurs (e.g. degraded image) set both switches to another
channel.
> Both units are now ready for use.
Note: Both units must always be set to the same channel.
Optional connection to audio equipment
1 Connect one end of the video cable (19) supplied to the video input
(yellow) of the SCART adapter (or directly to the yellow video input of
the TV) and the other end to the VIDEO output (15) of the receiver.
2 Connect the audio cable (18) supplied to the AUX input of the audio
equipment and the R-AUDIO-L outputs (15) of the receiver.
Make sure to insert the white and red plugs into the left (L) and right (R)
inputs.
Read the Instructions For Use of the audio equipment for the correct input.
R L TV R L TV
1 2 3 4 1 2 3 4
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO DC 9V
ON/OFF
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO DC 9V
ON/OFF
TPUT
VIDEO DC 9V
ON/OFF
TPUT
VIDEO DC 9V
ON/OFF
1 2 3 4 1 2 3 4
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO
1 2 3 4 1 2 3 4
AV SOURCE INPUT
R–AUDIO–L CHANNEL IR VIDEO
AV SOURCE INPUT
R–AUDIO–L CHANNEL IR VIDEO
R L TV R L TV
1 2 3 4 1 2 3 4
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO DC 9V
ON/OFF
TV OUTPUT
R–AUDIO–L CHANNEL VIDEO DC 9V
ON/OFF
ENGLISH 9
