BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
1-19H-13
15
50047982 HYDRAULIC ADAPTOR KIT
2045 LOADER
For Farmtrac 300DTC-FWA, 360DTC-FWA Tractors
1
Tractor Fitting
13
2
3
4
4
5
6
7
8
9
10
12
13
11
5
14
Note: Power Beyond Plug is shipped
in the Control Valve package.
4
REF. PART
NO. NO.
QTY. DESCRIPTION
1 25H51633 1 Straight Adaptor
2 25H51634 1 Straight Adaptor
3 25H51635 1 7/8” JIC Flare Swivel 90°
4 25H51636 3 37° Flare Swivel Reducer
5 25H43754 1 Hydraulic Hose 90”
6 25H51637 1 Straight Adaptor
7 63453 1 90° Adaptor JIC
8 24H43752 1 Hydraulic Hose 50”
9 25H46312 1 Swivel Elbow 45°
10 3050137 1 Adaptor
11 25H41174 1 45° Elbow
12 53338 1 90° Elbow
13 24H43753 1 Hydraulic Hose 70”
14 52161 4 Cable Tie
15 50047983 1 Instruction Sheet
SEPTEMBER, 2006
