BUSH HOG / MATERIAL HANDLING REPAIR PARTS MANUAL
1-19G-1
50044787 VALVE, HOSE & STAND KIT
For 2045 Loader
Used on Branson 2810, 3510, 3520, 4020 & 4520 Tractors
REF. PART
NO. NO.
QTY. DESCRIPTION
1 50044785 1 Tower Mount Plate
2 50044786 1 Valve Mount Upright
3 50034669 1 Valve Mount Extension
4 –––– 3 Capscrew 1/2” x 2-1/4” G5 ZP
5 –––– 3 Flatwasher 1/2” ZP
6 –––– 4 Lockwasher 1/2” CP
7 –––– 4 Hex Nut 1/2” CP
8 –––– 4 Capscrew 3/8” x 1-1/4” G5 ZP
9 –––– 6 Lockwasher 3/8” CP
10 –––– 6 Hex Nut 3/8” CP
11 50029328 1 Mount Plate, R.H.
12 50029327 1 Mount Plate, L.H.
13 –––– 2 Capscrew 3/8” x 1”
14 –––– 1 Flatwasher 3/8”
15 –––– 1 Capscrew 1/2” x 2”
16 50241788 1 Straight Fitting (BSPP 1/2”-14 F x 3/4” JICM)
17 50242242 1 Straight Fitting (BSPP 1/2”-14 M x 3/4” JICM)
18 50241786 1 Straight Fitting (BSPP 3/8”-19 ORM x 3/4” JICM)
19 25H42696 1 Straight Adapter
20 3050137 1 Male Adapter ORBM-JICM
21 53338 1 Str. Thread 90° Elbow (9/16” JICM x 9/16” ORBM)
22 25H49697 1 Hydraulic Hose 93” (9/16” JICF x 3/4” JICF)
23 50044784 1 Hydraulic Hose 130” (9/16” JICF x 3/4” JICF)
24 50044783 1 Hydraulic Hose 150” (9/16” JICF x 3/4” JICF)
25 52161 7 Cable Tie
26 25H49978 1 Valve, Small Walvoil
–––– 1 Hose Connection Assembly (See Valve Plumbing for M246 Loader)
–––– 1 Small Valve Mounting Assembly (See Valve Mounting Assembly for
Small Walvoil Valve)
27 50044788 1 Instruction Sheet
SEPTEMBER, 2006
