Connecting and Configuring your Router
13 12
Connecting and Configuring your Router
Verify the contents of your box. You should have the following:
• Belkin Wireless G Plus MIMO ADSL2+ Modem Router
• RJ11 Telephone Cord
• RJ45 Ethernet Networking Cable
• Power Supply
• Belkin Setup Assistant Software CD
• User Manual
Setup Assistant
Belkin has provided our Setup Assistant software to make installing
your Router a simple and easy task. You can use it to get your
Router up and running in minutes. The Setup Assistant requires that
your Windows 2000 ,XP or Vista computer be connected directly to
your ADSL and that the Internet connection is
active and working
at the time of installation. If it is not, you must use the “Alternate
Setup Method” section of this User Manual to configure your Router.
Additionally, if you are using an operating system other than Windows
2000,XP, or Mac OS X you must set up the Router using the “Alternate
Setup Method” section of this User Manual.
Step 1A: Hardware Connections – Follow the Quick Installation
Guide (QIG)
Brand-New Setup
Follow these steps if you are not replacing an existing modem. If you
are replacing an existing modem, skip to the next section, “Replacing
an Existing Modem or Modem Router”, starting on page 13
1A.1 Unpack your new Router from the box and place it next to your
computer. Raise the Router’s antennas.
1A.2 Retrieve the yellow RJ45 cable that was included with your
Router. First, connect one end to any yellow port labeled “Wired
Computers” on the back of your Router. Then, connect the other
end to the networking port on the back of your computer.
1A.3 Retrieve the included gray RJ11 phone cord. Connect one end
to the gray port labeled “DSL” on the back of your Router. Then
connect the other end to your ADSL connection (either a wall jack
or an ADSL splitter).
