Knowing your Router
9
se
ct
io
n
2
1
3
4
5
6
7
8
9
10
12
2. LAN Status LEDs
These LAN Status LEDs are labeled 1–4 and correspond to the
numbered ports on the rear of the Router. When a computer is properly
connected to one of the LAN ports on the rear of the Router, the LED
will light. Solid GREEN means a computer or a network-enabled device
is connected. When information is being sent over the port, the LED
blinks rapidly. ORANGE indicates a 10Base-T connection.
3. WLAN Status LED
The WLAN Status LED is solid GREEN when you enable the wireless
LAN function. It flashes when the Router is transmitting or receiving
data wirelessly.
4. ADSL LED
The ADSL LED flashes GREEN during negotiation with your ISP. It stays
GREEN when the Router is connected properly to your ADSL service.
Orange Ethernet link is up and 10Base-T
device connected
Orange - blinking 10Base-T device is transmitting or
receiving data
Green Ethernet link is up and 100Base-T
device is connected
Green - blinking 100Base-T device is transmitting or
receiving data
Green WLAN is up and connected
Green - blinking Transmitting or receiving data
OFF No ADSL connection
Green - blinking Negotiating connection
Green ADSL link is up and connected
