Computer Requirements
Parallel Interface Specifications
Interface Connector
Printer Side:
Amphenol FCN-685J036-L/X or equivalent
A shielded cable should be used.
Pin Assignment
Pin No.
Signal
Direction
Pin No.
Signal
Direction
1
DATA STROBE
Input
19
0V(S.G.)
-
2
DATA 1
Input
20
0V(S.G.)
-
3
DATA 2
Input
21
0V(S.G.)
-
4
DATA 3
Input
22
0V(S.G.)
-
5
DATA 4
Input
23
0V(S.G.)
-
6
DATA 5
Input
24
0V(S.G.)
-
7
DATA 6
Input
25
0V(S.G.)
-
8
DATA 7
Input
26
0V(S.G.)
-
9
DATA 8
Input
27
0V(S.G.)
-
10
ACKNLG
Output
28
0V(S.G.)
-
11
BUSY
Output
29
0V(S.G.)
-
12
PE
Output
30
0V(S.G.)
-
13
SLCT
Output
31
INPUT PRIME
Input
14
AUTO FEED
Input
32
FAULT
Output
15
N.C.
-
33
N.C.
-
16
0V (S.G.)
-
34
N.C.
-
17
0V (S.G.)
-
35
N.C.
-
18
+5V
-
36
SLCT IN
Input
Processor
Minimum Speed
Minimum
RAM
Recommended
RAM
Available Hard
Disk Space
Minimum System Requirements
Computer Platform
& Operating System Version
95, 98, 98SE
Me
NT
®
Workstation 4.0
2000 Professional
XP*
OS 8.5 – 8.51 (Printing Only)
OS 8.6 – 9.2
(Printing and Scanning)
Mac OS X v.10/10.1 (Printing Only)
Windows
®
Operating
Systems
Apple
iMac
TM
/iBook
TM
/
G3/G4 Operating
Systems
Pentium 75MHz
Pentium 150MHz
Pentium 75MHz
Pentium 133MHz
Pentium 233MHz
24MB
32MB
64MB
All base models meet minimun requirements
32MB
64MB
128MB
50MB
50MB
NOTE: USB is not supported under Windows
®
95 or Windows NT
®
4.0
All registered trademarks referenced herein are the property of their respective companies.
Printer Driver and Scanner Driver can be downloaded from http://solutions.brother.com
Printer Driver can be downloaded from http://solutions.brother.com
