Chapter 6
6-5
Calibration voltage (ADAM-5017/5018)
Module
Input Range Code
(Hex)
Input Range
Span Calibration
Voltage
00h ±15 mV +15 mV
01h ±50 mV +50 mV
02h ±100 mV +100 mV
03h ±500 mV +500 mV
04h ±1 mV +1 V
05h ±2.5 V +2.5 V
06h ±20 mV +20 mA (1)
0Eh
J thermocouple 0 to
1370°C
+50 mV
0Fh
K thermocouple 0 to
1370°C
+50 mV
10h
T thermocouple -100 to
400°C
+22 mV
11h
E thermocouple 0 to
1000°C
+80 mV
12h
R thermocouple 500 to
1750°C
+22 mV
13h
S thermocouple 500 to
1800°C
+22 mV
5018
14h
B thermocouple 500 to
1800°C
+152 mV
07h Not used
08h
ºC ±10 V
+10 V
09h ±5 V +5 V
0Ah ±1 V +1 V
0Bh ±500 mV +500 mV
0Ch ±150 mV +150 mV
5017
0Dh ±20 mA +20 mV (1)
Table 6-1: Calibration voltage of ADAM-5017/5018
