Analog Input module
4-12 ADAM 5000 IO modules User’s Manual
Technical specification of ADAM-5055S
Points
16
Digital Output
8 (8-channel/group)
Open collector to 40 V
200 mA max load per channel
Optical Isolation 2500 V
DC
Opto-isolator response time
25 µs
Supply Voltage 5 ~ 40 V
DC
Digital Input
8(4-channel/group) Dry Contact
Logic Level 0: close to GND Logic
Level 1: open Wet Contact Logic
Level 0: + 3 V max Logic Level 1: +
10 to 50 V
Dry Contact & Wet contact
Selectable
Optical Isolation 2500 V
DC
Opto-isolator response time
25 µs
Over-voltage Protect 70 V
DC
Power Consumption
0.68 W
LED Indicator
On when active
I/O Connector Type
21-pin plug-terminal
Table 4-5: Technical specification of ADAM-5055S
