Chapter 2
2-7
Technical specifications of ADAM-5017
Analog Input Channels
Eight differential
Input Type
mV, V, mA
Input Range
± 150 mV, ± 500 mV, ± 1 V, ± 5 V, ± 10 V and ± 20 mA
Isolation Voltage
3000 V
DC
Sampling Rate
10 samples/sec (total)
Analog Input Signal Limit
15 V max.
Max. allowable voltage difference
between two connectors in a
module
15 V max.
Input Impedance
2 Mohms
Bandwidth
13.1 Hz @ 50 Hz, 15.72 Hz @ 60 Hz
Accuracy
± 0.1% or better
Zero Drift
± 1.5 µV/°C
Span Drift
± 25 PPM/°C
CMR @ 50/60 Hz
92 dB min.
Power Requirements
+ 10 to + 30 V
DC
(non-regulated)
Power Consumption
1.2 W
Table2-2: Technical specifications of ADAM-5017
