Chapter 2
2-15
Technical specifications of ADAM-5018
Analog Input Channels
Seven differential
Input Type
mV, V, mA, Thermocouple
Input Range
± 15 mV, ± 50 mV, ± 100 mV, ± 500 mV, ± 1 V, ± 2.5
V and ± 20 mA
T/C Type and Temperature Range
JKTERSB 0 to 760 °C 0 to 1370 °C -100 to
400 °C 0 to 1400 °C 500 to 1750
°C 500 to 1750 °C 500 to 1800
°C
Isolation Voltage
3000 V
DC
Sampling Rate
10 samples/sec (total)
Input Impedance
2 Mohms
Bandwidth
13.1 Hz @ 50 Hz, 15.72 Hz @ 60 Hz
Accuracy
± 0.1% or better
Zero Drift
± 0.3 µV/°C
Span Drift
± 25 PPM/°C
CMR @ 50/60 Hz
92 dB min.
Power Consumption
1.2 W
Table 2-5: Technical specifications of ADAM-5018
