User’s Manual 3-25
Features, Utilities and Options
12. Tuck the keyboard ribbon cable into the groove under the palm rest.
Tuck the keyboard ribbon cable
13. Insert the tabs on the front of the keyboard into the corresponding
notches on the computer and place the keyboard down.
14. Screw the two screws and secure the keyboard.
15. Set the keyboard braces into its groove and press down to secure the
latches.
16. Install the battery pack. Refer to Replacing the battery pack section in
Chapter 6, Power and Power-Up Modes , for details.
17. Turn your computer over.
18. Turn the power on and make sure the added memory is recognized.
Click start, click Control Panel, click Performance and Maintenance
and select the System icon. Open System Properties window and
click General tab.
Removing a memory module
To remove the memory module, make sure the computer is in boot mode
then:
1. Set the computer to boot mode and turn the computer’s power off.
Make sure the Power indicator is off.
2. Remove AC adaptor and all cables connected to the computer.
Keyboard ribbon cable
Do not bend the keyboard ribbon cable.
When seating the keyboard, be sure to connect the circuit board if the
keyboard ribbon cable was pulled out while you were removing the
keyboard.
Be sure to use all two screws removed in step 7. Make sure no screw was
dropped into the computer. Make sure no foreign matter can be found.
