User’s Manual 2-7
The Grand Tour
Underside
The following figure shows the underside of the computer. Make sure the
display is closed before turning over your computer.
The underside of the computer
Notches
Battery lock Docking port Reserve Pen Battery pack
Battery release
latch
Notches Notches on the computer engage hooks on the
TOSHIBA Express Port Replicator to ensure a
secure connection.
Docking port This port enables connection of an optional
TOSHIBA Express Port Replicator and a Slice
Expansion Battery described in Chapter 3,
Features, Utilities and Options .
Keep foreign objects out of the docking port. A pin or similar object can
damage the computer’s circuitry. A plastic shutter protects the connector.
Battery pack The battery pack powers the computer when the
AC adaptor is not connected. For detailed
information on the battery pack, refer to
Chapter 6, Power and Power-Up Modes .
Battery lock Slide the battery lock to release the battery pack
for removal.
