User’s Manual 2-7
The Grand Tour
Underside
The following figure shows the underside of the computer. Make sure the
display is closed before turning over your computer.
The underside of the computer
Memory module cover Battery safety lock
Battery pack Battery release latch
Memory module
cover This cover protects memory module sockets.
Refer to the
Memory expansion section in
Chapter 9, Optional Devices.
Battery safety lock Slide the battery safety lock towards the release
position to make the battery release latch
movable.
Battery pack The battery pack powers the computer when the
AC adaptor is not connected. For detailed
information on the battery pack, refer to
Chapter 6,
Power .
Battery release
latch
Slide and hold this latch to release the battery
pack for removal.
For detailed information on removing the battery
packs, refer to Chapter 6,
Power .
