User’s Manual 9-14
Optional Devices
Installation
Connection via the S-Video out port
1. Plug one end of the S-Video out cable into the S-Video out port of your
computer.
Connecting the S-Video out port
2. Insert the other end of the S-Video out cable into the S1-/S2 video input
of the TV set (Use your computer’s speakers or a headphone to get
sound. Connect the headphone to the computer’s headphone jack).
Connection via the D-Video out port
1. Plug one end of the D-Video out cable into the D-Video out port of your
computer.
Connecting the D-Video out port
2. Insert the other end of the D-Video out cable into the video input
terminal of the TV set. (Use your computer's speakers or a headphone
to get sound. Connect the headphone to the computer’s headphone
jack).
Settings for display video on TV
To view video on the TV set, be sure to configure the following settings. If
not, nothing is displayed on the TV screen.
S-Video out port
D-Video out port
