User’s Manual 2-4
The Grand Tour
Right side
The following figure shows the computer’s right side.
The right side of the computer
Microphone jack Headphone (S/PDIF) jack
Optical media drive USB port Volume control
Volume control Use this dial to adjust the volume of the stereo
speakers or the stereo headphones.
Headphone (S/PDIF)
jack This jack lets you connect speakers or stereo
headphones (16 ohm minimum). When you
connect a speaker or headphones, the internal
speakers are automatically disabled.
This jack can be used also as S/PDIF jack and
enables connection of optical digital
correspondence apparatus.
Microphone jack A 3.5 mm mini microphone jack enables
connection of a three-conductor mini jack for
monaural microphone input.
Optical media drive The computer is configured with either a DVD
Super Multi drive or a DVD Super Multi drive with
Dual Layer support.
Universal
Serial Bus
(USB 2.0) port One Universal Serial Bus port is on the right side.
Refer to
Left side section, for details.
