—7—

ACCESSORY DESCRIPTION AND USE (Listed Alphabetically) Continued

17. Time Delay Relay

An SPST delay relay which briefly continues operation of the indoor blower motor to provide additional cooling after the compressor cycles off.

SUGGESTED USE: For improved efficiency ratings for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.

18. Winter Start Control

An SPST delay relay which bypasses the low-pressure switch for approximately 3 minutes to permit start-up for cooling operation under low load
conditions.

SUGGESTED USE: All air conditioners where Low-Ambient Controller has been added.

ACCESSORY USAGE GUIDELINE

* For tubing line sets greater than 50 ft and/or 20 ft vertical differential, refer to Residential Split-system Long-Line Application Guideline and Service Manual.
† Only when low-pressure switch is used.
‡ Required for Low-Ambient Controller (full modulation feature) and MotorMaster® Control only.

SOUND POWER (dBA)

ACCESSORY

REQUIRED FOR

LOW-AMBIENT

APPLICATIONS

(Below 55°F)

REQUIRED FOR

LONG-LINE

APPLICATIONS*

(Over 50 Ft)

REQUIRED FOR

SEA COAST

APPLICATIONS
(Within 2 Miles)

Crankcase Heater

Yes

Yes

No

Evaporator Freeze Thermostat

Yes

No

No

Winter Start Control

Yes†

No

No

Accumulator

No

No

No

Compressor Start Assist

Capacitor and Relay

Yes

Yes

No

MotorMaster® Control

or

Low-Ambient Pressure Switch

Yes

No

No

Wind Baffle

See Low-Ambient Instructions

No

No

Coastal Filter

No

No

Yes

Support Feet

Recommended

No

Recommended

Liquid-Line Solenoid Valve

or

Hard Shutoff TXV

No

See Long-Line

Application

Guideline

No

Ball Bearing Fan Motor

Yes‡

No

No

Unit
Size

Sound

Level

(dBA)

OCTAVE BAND CENTER FREQUENCY (Hz)

125

250

500

1000

2000

4000

8000

018-C, D

76

54.0

63.5

66.0

66.0

65.0

62.5

55.5

024-C, D

78

53.0

69.0

69.5

71.0

68.5

64.5

60.5

030-C, D

80

53.5

64.0

66.5

69.5

69.0

65.0

58.5

036-C, D

80

57.0

65.5

71.0

75.0

71.0

67.5

62.0

042-C, D

80

62.5

69.0

72.0

75.0

72.0

69.5

62.5

048-C

82

63.0

71.0

71.0

72.0

73.5

68.0

63.5

060-C

82

61.5

69.5

71.0

74.5

70.0

69.0

66.0
