—5—

SPECIFICATIONS Continued

* Permissible limits of the voltage range at which the unit will operate satisfactorily. Operation outside these limits may result in unit failure.

† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70).

The ampacity of nonmetallic-sheathed cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors per the NEC (ANSI/NFPA 70) Article
336-26. If other than uncoated (non-plated), 60° or 75°C (140° or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for
larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).

‡ Length shown is as measured 1 way along wire path between unit and service panel for a voltage drop not to exceed 2%.

** Fan motor with ball bearings required. See Low-ambient controller Installation Instructions for application.

NOTE: Copper wire must be used from service disconnect to unit. All motors/compressors contain internal overload protection.

UNIT SIZE

042-C, D

048-C

060-C

Operating Weight (Lb)

206

199

217

ELECTRICAL

Unit Volts—Hertz—Phase

208–230—60—1

Operating Voltage Range*

197—253

Compressor— Rated Load Amps

19.0

24.4

28.8

Locked Rotor Amps

105.0

140.0

165.0

Condenser Fan Motor—Full Load Amps

1.4

1.4

1.4

Min Unit Ampacity for Wire Sizing

25.2

31.9

37.4

Min Wire Size (75°C Copper) AWG†

10

10

8

Min Wire Size (60°C Copper) AWG†

10

8

8

Max Wire Length (Ft) (75°C Copper)‡

73

59

78

Max Wire Length (Ft) (60°C Copper)‡

77

97

82

Max Branch Circuit Fuse Size**

40

50

60

COMPRESSOR and REFRIGERANT

Compressor—Manufacturer and Type

Copeland Reciprocating

Millennium Scroll

Millennium Scroll

Temperature and Current Protection

Internal Line Break

Internal Line Break and Dome Thermostat

Refrigerant—Type and Amount (Lb)††

R-22 and 5.51

R-22 and 7.63

R-22 and 10.63

CONDENSER COIL and FAN

Coil Face (Sq Ft)

12.2

15.2

18.3

Fins per In.—Rows—Circuits

20—1—2

25—1—3

25—1—4

Fan Motor—HP, Type, and RPM

1/4 PSC and 1100

Volts—Hertz—Phase

208/230—60—1

Condenser Airflow (CFM)

3000

OPTIONAL EQUIPMENT

Support Feet

KSASF0101AAA

Coastal Filter

KAACF0801MED

Time Delay Relay

KAATD0101TDR

Cycle Protector

KSACY0101AAA

Crankcase Heater

Standard

KAACH1201AAA

Start Assist—Capacitor/Relay Type

KSAHS1301AAA

KSAHS1601AAA

Start Assist—PTC Type

KAACS0201PTC

Sound Hood

KSASH1201COP

KSASH2001CYL

TXV Kit (RPB)

KAATX0501RPB

KAATX0601RPB

KAATX0701RPB

TXV Kits (Hard Shutoff)

KSATX0601HSO

KSATX0701HSO

Low-Pressure Switch

KAALP0101LPS

High-Pressure Switch

KSAHI0101HPS

Filter Drier

P502-8163S (RCD)

Evaporator Freeze Thermostat**

KAAFT0101AAA

Liquid-Line Solenoid Valve

KAALS0101LLS

Winter Start Control**

KAAWS0101AAA

Low-Ambient Kit

KSALA0201R22

MotorMaster® Control††

32LT660004 (RCD)

Ball Bearing Fan Motor

HC40GE232 (RCD)

Thermostat, Auto Changeover,

Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool

TSTATBBNAC01-B

Thermostat, Auto Changeover,

7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool

TSTATBBPAC01-B

Builder’s Thermostat, Manual

Changeover, Non-Programmable,
°F/°C, 1-Stage Heat, 1-Stage Cool

TSTATBBBAC01-B

Thermidistat™ Control—Programmable/

Non-Programmable Thermostat with
Humidity Control

TSTATBBPRH01-B

Outdoor Air Temperature Sensor

TSTATBBSEN01-B

Backplate for Non-Programmable

Thermostat

TSTATXXNBP01

Backplate for Programmable Thermostat

TSTATXXPBP01

Backplate for Builder’s Thermostat

TSTATXXBBP01

Thermostat Conversion Kit (4 to 5 wire)

— 10 Pack

TSTATXXCNV10
