COMBINATION RATINGS Continued
* Tested combination.
† In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Bryant furnaces are equipped with TDR.
‡ Based on computer simulation, TXV must be hard shutoff type.
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other com-
binations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
UNIT
SIZE-SERIES
INDOOR
MODEL
TOT.
CAP.
BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
STANDARD
RATING
BRYANT GAS
FURNACE OR
ACCESSORY
TDR†
ACCESSORY
TXV‡
060-C
CC5A/CD5AW060*
57,000
NONE
10.20
10.50
10.50
CC5A/CD5AA060
54,500
NONE
10.00
10.20
10.20
CE3AA060
57,500
NONE
10.20
10.50
10.50
CK3BA060
54,500
NONE
10.00
10.20
10.20
CK5A/CK5BA060
54,500
NONE
10.00
10.20
10.20
CK5A/CK5BN060
54,500
NONE
10.00
10.20
10.20
CK5A/CK5BX060
57,000
NONE
10.20
10.50
10.50
F(A,B)4(A,B)N(F,B)060
57,500
TDR
10.00
—
10.00
FB4(A,B)NB070
58,500
TDR
10.50
—
10.50
FC4(B,C)NB070
58,500
TDR & TXV
10.50
—
—
FC4(B,C)N(F,B)060
57,500
TDR & TXV
10.00
—
—
FG3AAA060
56,500
NONE
10.20
10.50
10.50
FK4(C,D)NB006
58,000
TDR & TXV
11.00
—
—
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CC5A/CD5AA060
55,000
TDR
10.5
10.5
9
CE3AA060
56,500
TDR
10.5
10.5
9.3
CK3BA060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BA060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BT060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BX060
56,500
TDR
10.5
10.5
9.4
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CC5A/CD5AA060
55,000
TDR
10.5
10.5
9
CC5A/CD5AW060
56,000
TDR
10.5
10.5
9.25
CE3AA060
56,500
TDR
10.5
10.5
9.3
CK3BA060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BA060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BT060
56,000
TDR
10.5
10.5
9.15
CK5A/CK5BX060
56,500
TDR
10.5
10.5
9.4
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CC5A/CD5AA060
55,000
TDR
10.5
10.5
9.1
CC5A/CD5AW060
56,000
TDR
10.5
10.5
9.3
CE3AA060
56,500
TDR
10.5
10.5
9.35
CK3BA060
56,000
TDR
10.5
10.5
9.2
CK5A/CK5BA060
56,000
TDR
10.5
10.5
9.2
CK5A/CK5BT060
56,000
TDR
10.5
10.5
9.2
CK5A/CK5BX060
56,500
TDR
10.5
10.5
9.45
