—22—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
593C048-C Outdoor Section With CC5A/CD5AA048 Indoor Section
1450
72 54.9 27.0 4.53 52.6 26.2 4.93 50.1 25.3 5.37 47.5 24.3 5.85 44.8 23.4 6.36
67 50.1 34.1 4.42 47.9 33.2 4.81 45.7 32.3 5.25 43.3 31.3 5.72 40.8 30.3 6.22
62 45.6 41.0 4.33 43.6 40.0 4.72 41.5 39.0 5.14 39.3 37.8 5.60 37.1 36.5 6.09
57 43.5 43.5 4.29 41.9 41.9 4.68 40.3 40.3 5.11 38.6 38.6 5.58 36.8 36.8 6.07
1600
72 55.6 27.9 4.61 53.2 27.0 5.01 50.7 26.1 5.44 48.1 25.2 5.92 45.3 24.2 6.44
67 50.8 35.6 4.50 48.6 34.7 4.89 46.2 33.7 5.32 43.8 32.8 5.80 41.2 31.8 6.29
62 46.3 42.9 4.40 44.2 41.9 4.79 42.1 40.7 5.22 39.9 39.4 5.68 37.7 37.7 6.17
57 44.7 44.7 4.37 43.1 43.1 4.76 41.4 41.4 5.20 39.6 39.6 5.67 37.7 37.7 6.17
1750
72 56.2 28.7 4.69 53.8 27.8 5.08 51.2 26.9 5.52 48.5 25.9 6.00 45.7 24.9 6.51
67 51.4 37.0 4.57 49.1 36.1 4.96 46.7 35.1 5.40 44.2 34.2 5.87 41.6 33.1 6.37
62 46.8 44.7 4.47 44.7 43.5 4.86 42.6 42.2 5.29 40.5 40.5 5.76 38.5 38.5 6.26
57 45.8 45.8 4.45 44.1 44.1 4.85 42.3 42.3 5.28 40.4 40.4 5.76 38.5 38.5 6.26
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 1.00 1.00 CK3BA 048 0.98 0.93
CC5A/CD5AC 048 0.98 0.99 060 1.00 0.93
CC5A/CD5AW 048 1.00 1.00 CK5A/CK5BA 048 0.98 0.93
060 1.03 1.01 060 1.00 0.93
CD5AA 048 1.00 1.00 CK5A/CK5BT 048 0.98 0.93
CE3AA 048 1.01 1.00 060 1.00 0.93
060 1.04 1.02 CK5A/CK5BW 048 0.98 0.93
CF5AA 048 1.00 0.99 CK5A/CK5BX 060 1.01 0.92
CK3BA 048 1.00 1.00 COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
060 1.00 1.01 CC5A/CD5AA 060 0.99 0.94
CK5A/CK5BA 048 1.00 1.00 CC5A/CD5AC 048 0.98 0.94
060 1.00 1.01 CC5A/CD5AW 048 0.98 0.93
CK5A/CK5BN 048 0.97 0.98 060 1.00 0.93
060 1.00 1.01 CD5AA 048 0.98 0.93
CK5A/CK5BW 048 1.00 1.00 CE3AA 048 0.98 0.93
CK5A/CK5BX 060 1.03 1.01 060 1.00 0.93
F(A,B)4A(A,B)N(F,B) 048 1.01 1.02 CK3BA 048 0.98 0.93
060 1.04 1.05 060 1.00 0.93
FB4(A,B)NB 070 1.04 1.02 CK5A/CK5BA 048 0.98 0.93
FC4(B,C)N(F,B) 048 1.01 1.02 060 1.00 0.93
060 1.03 1.04 CK5A/CK5BT 048 0.98 0.93
FC4(B,C)NB 054 1.04 1.02 060 1.00 0.93
070 1.04 1.02 CK5A/CK5BW 048 0.98 0.93
FG3AAA 048 1.00 1.00 CK5A/CK5BX 060 1.01 0.92
060 1.03 1.01 COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
FK4(C,D)NB 006 1.04 0.95 CC5A/CD5AA 060 0.99 0.93
FK4(C,D)NF 005 1.03 0.96 CC5A/CD5AC 048 0.98 0.93
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE CC5A/CD5AW 048 0.98 0.93
CC5A/CD5AC 048 0.98 0.95 060 1.00 0.92
CD5AA 048 0.98 0.95 CD5AA 048 0.98 0.93
CE3AA 048 0.98 0.95 CE3AA 048 0.98 0.93
060 1.00 0.94 060 1.00 0.92
CK3BA 048 0.98 0.95 CK3BA 048 0.98 0.93
CK5A/CK5BA 048 0.98 0.95 060 1.00 0.92
CK5A/CK5BT 048 0.98 0.95 CK5A/CK5BA 048 0.98 0.93
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE 060 1.00 0.92
CC5A/CD5AA 060 0.99 0.94 CK5A/CK5BT 048 0.98 0.93
CC5A/CD5AC 048 0.98 0.94 060 1.00 0.92
CC5A/CD5AW 048 0.98 0.93 CK5A/CK5BW 048 0.98 0.93
CD5AA 048 0.98 0.93 CK5A/CK5BX 060 1.01 0.92
CE3AA 048 0.98 0.93 — — —
060 1.00 0.92
