CONDENSER ONLY RATINGS* Continued
* ARI listing applies only to systems shown in Ratings and Performance table.
KW
— Total Power (kW)
SDT
— Saturated Temperature Leaving Compressor (°F)
SST
— Saturated Temperature Entering Compressor (°F)
TCG
— Gross Cooling Capacity (1000 Btuh)
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55
65
75
85
95
105
115
593C042-C, D
TCG
40.6
37.9
35.2
32.5
29.7
26.9
24.1
30
SDT
81.5
90.4
99.4
108.0
118.0
127.0
136.0
KW
2.56
2.76
2.94
3.10
3.23
3.33
3.43
TCG
44.8
42.0
39.2
36.3
33.4
30.4
27.5
35
SDT
83.7
92.5
101.0
110.0
119.0
128.0
137.0
KW
2.63
2.85
3.05
3.23
3.38
3.51
3.64
TCG
49.3
46.3
43.3
40.3
37.2
34.1
31.0
40
SDT
86.1
94.8
104.0
112.0
121.0
130.0
139.0
KW
2.69
2.93
3.16
3.36
3.54
3.69
3.84
TCG
54.0
50.9
47.7
44.5
41.2
38.0
34.7
45
SDT
88.7
97.2
106.0
115.0
123.0
132.0
141.0
KW
2.76
3.02
3.26
3.49
3.69
3.87
4.04
TCG
58.9
55.7
52.3
48.9
45.5
42.0
38.6
50
SDT
91.4
99.8
108.0
117.0
126.0
134.0
143.0
KW
2.82
3.10
3.37
3.62
3.85
4.04
4.24
TCG
64.1
60.7
57.1
53.6
49.9
46.3
42.7
55
SDT
94.3
103.0
111.0
120.0
128.0
137.0
145.0
KW
2.89
3.19
3.48
3.75
4.00
4.22
4.44
593C048-C
TCG
44.5
42.6
40.6
38.5
36.4
34.2
31.9
30
SDT
80.0
89.8
99.6
109.0
119.0
129.0
139.0
KW
2.76
3.03
3.34
3.68
4.05
4.45
4.87
TCG
48.7
46.7
44.5
42.3
40.1
37.7
35.2
35
SDT
81.8
91.5
101.0
111.0
121.0
131.0
140.0
KW
2.81
3.09
3.39
3.74
4.12
4.53
4.96
TCG
53.1
50.9
48.7
46.4
43.9
41.4
38.8
40
SDT
83.7
93.3
103.0
113.0
123.0
132.0
142.0
KW
2.86
3.14
3.45
3.80
4.19
4.60
5.05
TCG
57.8
55.5
53.1
50.6
48.0
45.3
42.5
45
SDT
85.8
95.3
105.0
115.0
124.0
134.0
144.0
KW
2.92
3.20
3.52
3.87
4.26
4.68
5.14
TCG
62.7
60.2
57.7
55.0
52.3
49.4
46.5
50
SDT
88.0
97.4
107.0
117.0
126.0
136.0
146.0
KW
2.99
3.27
3.59
3.95
4.34
4.77
5.24
TCG
67.9
65.3
62.5
59.7
56.8
53.7
50.6
55
SDT
90.4
99.8
109.0
119.0
128.0
138.0
147.0
KW
3.06
3.35
3.67
4.03
4.42
4.86
5.33
593C060-C
TCG
55.9
53.4
50.9
48.2
45.4
42.5
39.5
30
SDT
84.5
94.2
104.0
114.0
124.0
134.0
143.0
KW
3.47
3.82
4.22
4.65
5.13
5.64
6.16
TCG
61.1
58.4
55.7
52.8
49.8
46.7
43.5
35
SDT
86.7
96.4
106.0
116.0
126.0
136.0
145.0
KW
3.54
3.90
4.31
4.75
5.23
5.75
6.31
TCG
66.6
63.7
60.8
57.7
54.5
51.2
47.8
40
SDT
89.0
98.7
108.0
118.0
128.0
138.0
147.0
KW
3.63
3.99
4.40
4.85
5.35
5.88
6.45
TCG
72.3
69.3
66.1
62.8
59.5
56.0
52.4
45
SDT
91.4
101.0
111.0
120.0
130.0
140.0
150.0
KW
3.72
4.09
4.50
4.96
5.47
6.01
6.60
TCG
78.3
75.1
71.8
68.3
64.7
60.9
57.1
50
SDT
94.1
104.0
113.0
123.0
132.0
142.0
152.0
KW
3.82
4.20
4.62
5.08
5.59
6.15
6.75
TCG
84.7
81.2
77.6
73.9
70.1
66.1
62.0
55
SDT
96.8
106.0
116.0
125.0
135.0
144.0
154.0
KW
3.93
4.31
4.74
5.21
5.73
6.29
6.91
