—20—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
593C042-C, D Outdoor Section With CC5A/CD5AA042 Indoor Section
1225
72 45.2 22.4 4.01 42.6 21.4 4.25 40.1 20.5 4.48 37.6 19.6 4.72 35.1 18.7 4.95
67 41.2 28.3 3.89 38.8 27.4 4.11 36.6 26.4 4.33 34.3 25.5 4.55 32.0 24.6 4.77
62 37.4 34.0 3.77 35.3 32.9 3.97 33.2 31.8 4.18 31.1 30.6 4.39 29.1 29.1 4.60
57 35.9 35.9 3.72 34.2 34.2 3.93 32.5 32.5 4.15 30.8 30.8 4.38 29.1 29.1 4.59
1400
72 46.0 23.4 4.10 43.3 22.4 4.34 40.6 21.4 4.57 38.1 20.6 4.82 35.5 19.7 5.05
67 42.0 30.1 3.98 39.5 29.1 4.20 37.1 28.1 4.43 34.8 27.2 4.65 32.4 26.3 4.87
62 38.2 36.2 3.86 36.1 35.0 4.08 34.0 33.7 4.30 31.9 31.9 4.51 30.1 30.1 4.74
57 37.3 37.3 3.83 35.5 35.5 4.05 33.7 33.7 4.28 31.9 31.9 4.51 30.1 30.1 4.73
1575
72 46.5 24.3 4.19 43.8 23.3 4.43 41.2 22.4 4.67 38.4 21.4 4.90 35.8 20.6 5.14
67 42.5 31.7 4.06 40.0 30.7 4.29 37.5 29.7 4.52 35.1 28.8 4.74 32.6 27.8 4.96
62 38.9 38.1 3.95 36.7 36.6 4.17 34.8 34.8 4.40 32.8 32.8 4.63 30.9 30.9 4.86
57 38.5 38.5 3.94 36.6 36.6 4.16 34.7 34.7 4.40 32.8 32.8 4.63 30.9 30.9 4.85
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 042 1.00 1.00 CD5AA 048 1.00 0.93
CC5A/CD5AC 048 0.99 1.00 CE3AA 042 0.99 0.92
CC5A/CD5AW 042 1.00 1.00 048 1.00 0.93
048 1.01 1.00 CK3BA 042 0.99 0.93
CE3AA 042 1.00 1.00 048 1.00 0.93
048 1.00 1.00 CK5A/CK5BA 042 0.99 0.92
CF5AA 048 1.01 1.00 048 1.00 0.93
CK3BA 042 1.00 1.00 CK5A/CK5BT 042 0.99 0.93
048 1.01 1.00 048 1.00 0.93
CK5A/CK5BA 042 1.00 1.00 CK5A/CK5BW 048 1.00 0.93
048 1.01 1.00 COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CK5A/CK5BN 042 0.97 1.00 CC5A/CD5AA 042 0.99 0.93
048 0.99 1.00 CC5A/CD5AC 048 0.98 0.91
CK5A/CK5BW 048 1.01 1.00 CC5A/CD5AW 042 0.99 0.93
F(A,B)4(A,B)N(F,B) 042 1.00 1.01 048 1.00 0.93
048 1.03 1.02 CD5AA 048 1.00 0.92
FC4(B,C)N(F,B) 042 1.00 1.01 CE3AA 042 0.99 0.92
048 1.03 1.02 048 1.00 0.93
FG3AAA 048 0.10 1.00 CK3BA 042 0.99 0.93
FK4(C,D)NF 003 1.01 0.92 048 1.00 0.93
005 1.04 0.95 CK5A/CK5BA 042 0.99 0.92
FK4(C,D)NB 006 1.05 0.94 048 1.00 0.93
COILS + 315(A,J)AV048090 VARIABLE-SPEED FURNACE CK5A/CK5BT 042 0.99 0.93
CC5A/CD5AA 042 0.99 0.94 048 1.00 0.93
CC5A/CD5AC 048 0.98 0.92 CK5A/CK5BW 048 1.00 0.93
CD5AA 048 1.00 0.94 COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CE3AA 042 0.99 0.93 CC5A/CD5AA 042 0.99 0.92
048 1.00 0.94 CC5A/CD5AC 048 0.98 0.91
CK3BA 042 0.99 0.93 CC5A/CD5AW 042 0.99 0.93
048 1.00 0.94 048 1.00 0.92
CK5A/CK5BA 042 0.99 0.93 CD5AA 048 1.00 0.92
048 1.00 0.94 CE3AA 042 0.99 0.92
CK5A/CK5BE 042 0.99 0.93 048 1.00 0.93
CK5A/CK5BT 042 0.99 0.93 CK3BA 042 0.99 0.92
048 1.00 0.94 048 1.00 0.92
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE CK5A/CK5BA 042 0.99 0.92
CC5A/CD5AA 042 0.99 0.93 048 1.00 0.92
CC5A/CD5AC 048 0.98 0.91 CK5A/CK5BT 042 0.99 0.92
CC5A/CD5AW 042 0.99 0.93 048 1.00 0.92
048 1.00 0.93 CK5A/CK5BW 048 1.00 0.92
