5. Getting started
5.3 Terminology overview
Overview
The following table gives an overview of the different functionalities of the keys.
Image 5-7
1 Function keys user programmable keys with functions for direct access.
2 MENU Menu key, to enter or exit the Toolbar menu.
3 Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed
address key with a pencil, followed by pressing one digit button between 0 and 9.
4 LOGO key allows to recall the stored Logo (not in PiP mode)
5 PAUSE to stop projection for a short time, press ’PAUSE’. The image disappears but full power is
retained for immediate restarting.
6 STBY standby button, to start projector when the power switch is switched on and to switch off the
projector without switching off the power switch.
Attention : Switching to Standby. When the projector is running and you want to
go to standby, press the standby key for 2 seconds.
7 MUTE to interrupt the sound reproduction (audio = optional.
8 AUTOIMAGE Auto image, to center the image on the active LCD surface.
9 Digit buttons direct input selection.
9b SOURCE button this button allows to switch through the active (scanned) inputs
