5. Getting started
5. GETTING STARTED
Overview
•
•
•
•
•
•
•
•
•
•
•
5.1 Quick startup
The executive RCU
The executive RCU is used for quick acces and allows basic control over the projector.
Dual head setup
In a dual head setup, the two projector are default programmed with respectively projector address 1 and 2.
In order to control the right projector , the executive RCU has to be programmed with the right address.
This done by pressing the numeric key 1 or 2 depending on the projector to be controlled.
1
2
ENTER
BACK
SOURCE
AUTO
PIP
B
A R C O
M
GP
PROJECTOR 1
PROJ ADDRESS = 1
PROJECTOR 2
PROJ ADDRESS =
Image 5-1
In case of a single projector setup the projector should respond to address 1.
Otherwise, set the projector address to 1 in the Installation menu.
