❖ Note : All Asanté MAUS attached to
a hub or repeater should have HBE
disabled. For example, if the Mini
MAU is attached to an AsantéHub
1012 or 2072.
❖
Installing a Mini MAU for the
AsantéHub 2072
To install an Asanté Mini MAU into the
recessed port on the double-slotted
AsantéHub 2072 do the following:
1
Unscrew the two ejector
screws on each side of the
module’s front panel and pull
out the module approximately
four to five inches from the
chassis.
2
Remove the Mini MAU’s filler
plate on the AsantéHub.
