Mini MAU Page 20
Switches for 10Base2 MAU
The default settings are identified below:
❏ Termination disabled
(1, switch UP)
❏ HBE disabled
(1, switch UP)
Termination
The Mini 10Base2 MAU has a built-in
50ohm termination resistor. This is useful if
the user does not have a terminator. If
enabled the switch is in the “Down” (0)
position and the 50 ohm termination is
connected across the BNC.
HBE
The HBE can be disabled on the Mini
10Base2 MAU by setting the DIP switch to
the “UP” (1) position. This is the default
setting.
