Switches for 10Base-F MAU
The default settings are identified below:
❏ Loopback Test Switch
enabled.
(1, switch UP)
❏ HBE Switch disabled.
(1, switch UP)
The default settings are Loopback switch
enabled and HBE Switch disabled.
Loopback Test Switch
When this switch is enabled the AUI trans-
mit pair data is looped back to the AUI
receiver pair. This test can be used for trou-
bleshooting to determine if the returned
signal is the same as the transmitted sig-
nal.
This switch can be disabled.
HBE Switch
The HBE of the Mini 10BaseFL can be dis-
abled by setting the DIP switch to the “UP”
(1) position.
