Asante Technologies 10Base2 User Manual
Page 22

Mini MAU
Page
19
Mini 10Base2 MAU
LED
Color
Status
Power ON Green
MAU ON
receiving power
from AUI
HBE ON
Green
ON HBE is ON
Switch set to
“Down” (0) posi-
tion.
Receive
Green
On
MAU is receiving or
transmitting
Transmit
Green
ON
MAU is transmitting
Jabber
Yellow
ON
Transceiver stops
transmitting due to
a packet transmis-
sion exceeding
more than 20 ms.
Collision
Yellow
ON
Collision on Net-
work
